IC OPAMP GP 60KHZ RRO 6DFN
| Part Number | LT6000CDCB#TRPBF |
| Date Code | 2140 |
| Quantity Available | 1673 pcs |
| Manufacturer | Linear Technology/Analog Devices |
| Lead Time | Ship within 24 hours |
| QTY | 1000 |
| Datasheet | LT6000.pdf |
| Minimum Quantity | More than 50pcs |
| Distributor | SingSun |
| RoHS Status | Lead free / RoHS Compliant |
| Ship From | Hong Kong |
| Shipment Way | EMS/SF/DHL/TNT/UPS/FedEx |
| Country of Assembly | THAILAND |
| Country of Diffusion | UNITED STATES |
| Lot Number | ZF17547.31 |
| MSL | 3 |
| Packaging | Tape & Reel (TR) |
| Base Product Number | LT6000 |
| Series | - |
| Amplifier Type | General Purpose |
| Number of Circuits | 1 |
| Output Type | Rail-to-Rail |
| Slew Rate | 0.018 V/μs |
| Gain Bandwidth Product | 60kHz |
| -3db Bandwidth | - |
| Current - Input Bias | 4nA |
| Voltage - Input Offset | 500μV |
| Current - Supply | 20μA |
| Current - Output / Channel | 10mA |
| Voltage - Supply, Single/Dual (±) | 1.8 V ~ 16 V, ±0.9 V ~ 8 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-WFDFN Exposed Pad |
| Supplier Device Package | 6-DFN (2x3) |
The LT6000CDCB#TRPBF is single precision rail-to-rail input and output operational amplifiers. Designed to maximize battery life in always-on applications, the devices will operate on supplies down to 1.8V while drawing only 13µA quiescient current. The low supply current and low voltage operation is combined with precision specifications; input offset is guaranteed less than 600µV. The performance on 1.8V supplies is fully specified and guaranteed over temperature. A shutdown feature available in the LT6000 and the 10-lead dual LT6001 version can be used to extend battery life by allowing the amplifiers to be switched off during periods of inactivity.
The LT6000CDCB#TRPBF is available in a tiny, dual fine pitch leadless DFN package. These devices are specified over the commercial and industrial temperature range.
